Internal pipe Abrasive Blasting Machine

Abrasive Blasting Machine Shot Blasting Machine

We are offering two pneumatic models of internal pipe Abrasive blasting machine used for cleaning inside the diameter of the pipe (ranging 51-914mm) and up to 40 feet. These tools are easy to operate and no rotation of heavy pipes is required, hence saving time and expenditure. The tool is inserted into hollow pipes coupled with portable Abrasive blaster via blasting hose and carried on lightweight centering carriage, the tool is further pushed manually from one end to the other. Thus, blasting is offered to eliminate old paints, unreasonable rust, carbon mill scale, etc. to achieve a white metal finish (ideal toward further coating).

Salient Features Of Internal Pipe Blasting Equipment:

360° blasting of the internal diameter of the pipe (2”-36” & 12 Mtr Length) for removal of any kind of contamination.
Non-rotation of heavy pipes.
Economic, efficient, and Light Weight for effortless handling.
Pneumatically operated, no electricity required.
Attached to suitable Portable Abrasive blasting machine Models (SB PORT 150/300/500/0/1000), easy setup.
Supplied with centering collar and adjustable centering carriage to suit a varied range of pipe diameters.
Supported any abrasive mesh 18-40 (except river garnet/sand, aluminum oxide, and silicon oxide).
Industrial applications: Refineries, Pipe Liners/Manufacturers, Shipyard Water, Gas, and Chemical Factories, etc.

Types Of Internal Pipe Blasting:

(I) pipe Abrasive blasting equipment, SB IPBT

Ideal for small ID 50mm – 300mm.
No moving part cleans through the continuous circular motion of blast stream
Obtained with the aid of the Tungsten Carbide deflector tip.
High-Quality TC parts, ensuring a longer life.
Light Weight (5 Kgs) for easy handling.
Centering Collars assist to increase range.

(II) pipe Abrasive blasting equipment, SB IRBT (ROTO BLAST)

Regularly recognized as ‘Rotoblast’, as rotating head are driven via compressed air, carrying two nozzles positioned radially running at constant velocity to provide uniform and even blasting.
The Machine comes with 3 leg support for better grip, centering carriage and two TC lined nozzles.

Technical specifications table:

Technical Specifications	SB IPBT	SB IRB T(A)	SB IRBT (B)	SB IRBT(C)
Nozzle Size (mm) No. of Nozzle	12.5 1	6 2	8 2	10 2
Pipe ID to be cleaned (mm) (inch)	51-305 (2-12)	165-254 (6-10)	254-600 (10-24)	600-914 (24-36)
Compressed air consumption (cfm) at 90psi	200	250	365	600
Dimension (mm)	230x110x610	180x180x880	180x180x880	180x180x880
Approx. Weight (kgs.)	5	15	15	15
